Polyolefin adhesion system CEMEDINE PPX SET (Instant Adhesives + Primer)
Polyolefin adhesion system
Adhesion of adhesion-resistant materials such as polyethylene, polypropylene, silicone rubber, polyacetal and fluorocarbon resin in a short time. (Combined use of surface modification primer PPX-3 and Instant Adhesives Cemedine PPX)
Features
- Instant Adhesives (CEMEDINE PPX)
Shows superior high-speed curing property.
Broader adhesive range is made possible with PPX only.
- Primer (PPX-3)
Performance improvement of adhesion to polyethylene is far superior.
Surface coating is simply formed by painting with cotton swabs, brush and sprays.
Product data
Durability / chemicals resistance
(MPa)
| Tensile shear adhesive strength |
PP |
HDPE |
LDPE |
| Normal state adhesive strength |
5.5* |
4.5* |
1.6* |
| Durability |
Heat resistance |
70°C for 7 days |
4.8* |
3.7 |
1.7* |
| Water resistance |
40°C for 7 days |
5.4* |
4.4* |
1.6* |
| Moisture resistance |
60°C,95％RH×7days |
5.2* |
3.9 |
1.4* |
Heat cycle
(-30°Cx3hours+70°Cx3hours)x10cycles |
5.3* |
4.2* |
1.7* |
| Chemical resistance |
Gasoline |
25°C for 7 days |
4.6* |
3.9* |
1.3 |
| Kerosene |
25°C for 7 days |
4.9* |
3.9* |
1.5* |
| Methanol |
25°C for 7 days |
5.4* |
2.8 |
0.7 |
| Window washing liquid |
25°C for 7 days |
5.3* |
4.4* |
1.6* |
*…indicates material failure
Property
| |
PPX SET (For difficult to bond materials) |
Instant Adhesives
CEMEDINE PPX |
Primer
PPX-3 |
| Application / Properties / Features |
For Polyolefin |
| External appearance |
Colorless transparent |
Colorless transparent |
| Flash point |
°C |
85 |
-1 |
| Ignition point |
°C |
485 |
215 |
| Freezing point |
°C |
≤-20 |
≤-20 |
| Viscosity |
mPa･s/23°C |
10 |
≤1 |
| Specific gravity |
g/cm3 |
1.05 |
0.68 |
| Set time |
23°C |
5 s |
|
| Tensile shear adhesive strength (PP) |
MPa |
5.5 MF |
| Application method |
Apply right from the container |
Cotton swabs,Brush |
| Capacity |
60g set |
| 20g |
200mL |
